TECHNICAL SPECIFICATIONS

ENGINE MODEL

John Deere 6068HFG05

OUTPUT @ RATED SPEED (1,800 RPM)

235 HP

PRIME POWER

150 kVA / 120 kW

STANDBY POWER

165 kVA / 132 kW

VOLTAGE SINGLE PHASE (SWITCHABLE)

120V / 240V / 277V

VOLTAGE THREE PHASE (SWITCHABLE)

208V / 240V / 416V / 480V

AMPERAGE SINGLE PHASE 120V

363 A x 2

AMPERAGE SINGLE PHASE 240V

363 A

AMPERAGE THREE PHASE 208V

394 A

AMPERAGE THREE PHASE 240V

361 A

AMPERAGE THREE PHASE 480V

180 A

RUN TIME @ FULL LOAD

24 hrs

INTEGRAL FUEL TANK CAPACITY

204 gal

EPA EMISSION LEVEL

Tier 4 Final

OPERATING WEIGHT

8,488 lbs

DRY WEIGHT

6,878 lbs

GVWR

9,838 lbs

TRAILER WEIGHT

1,350 lbs

DIMENSIONS (WITHOUT TRAILER)

113.4" L x 51.2" W x 72.8" H

DIMENSIONS (WITH TRAILER)

196" L x 79" W x 85" H
