ALLMAND

MAXI-POWER

MP65

.

Standby Power kVA(kW) 67 kVA / 53.6 kW

Prime Power - kVA(kW) 63 kVA / 50 kW

Armature Connection Star with Neutral/Zig/Zag

Number of Poles 4

Frequency - Hz (switch-able) 60 Hz (50 Hz)

Voltage Single Phase (Switch-able) 120 V / 240 V / 277 V

Voltage Three Phase (Switch-able) 208 V / 240 V / 416 V / 480 V

Amperage Single Phase 120 V (A) 152 A x 2

Amperage Single Phase 240 V (A) 152 A

Amperage Three Phase 208 V (A) 167 A

Amperage Three Phase 240 V (A) 152 A

Amperage Three Phase 480 V (A) 76 A

Engine Brand Isuzu

Engine Model 4JJ1X

EPA Emissions Certified Tier 3 Flex

Output @ Rated Speed (1,800 RPM) - HP 98 HP

Integral Fuel Tank Capacity (gal) 106 gallons

Run Time @ Full Load (hrs) 28+ hours

Sound Level @ 23 ft (No Load) - dBA < 63 dBA

Trailer Length 140 in

Trailer Width 66 in

Combined Weight of Trailer and Generator 4680 lbs
